Leuze PRK25CL1.1-4P/M12 50139656 Retro-reflective Photoelectric Sensors

The Leuze PRK25CL1.1-4P/M12 is a high-precision Retro-reflective Photoelectric Sensor (Part No. 50139656) designed for reliable object detection, rapid switching, and stable signal transmission. Manufactured by Leuze, this Retro-reflective Photoelectric Sensors component supports consistent monitoring of automated processes, ensuring accurate detection of both moving and stationary parts in industrial systems.

Datasheet

Brand	Leuze
Model Number	PRK25CL1.1-4P/M12

Leuze PRK25CL1.1-4P/M12 50139656 Retro-reflective Photoelectric Sensors - Technical Specifications

Specification	Value
Operating principle	Reflection principle
Operating voltage	0.2 ... 20 m (guaranteed operating range), With reflector TK(S) 100x100
Number of connections	1 Piece(s)
Type of connection	Connector
Thread size	M12
Type	Male
Material	PUR
No. of pins	4 -pin
Encoding	A-coded
Ambient temperature, operation	-40 ... 60 °C
Ambient temperature, storage	-40 ... 70 °C
Degree of protection	IP 67, IP 69K
Net weight	22 g
Beam path	Collimated
Light source	LED, Red
Wavelength	650 nm
Supply voltage	10 ... 30 V, DC, Incl. residual ripple
Residual ripple	0 ... 15 %, From UB
Open-circuit current	0 ... 20 mA
Number of digital switching outputs	2 Piece(s)
Switching element	Transistor, PNP
Switching principle	Light switching
Switching frequency	2,500 Hz
Response time	0.2 ms
Dimension (W x H x L)	15 mm x 42.7 mm x 30 mm
Housing material	Plastic
Plastic housing	ABS
Housing color	Red
Type of display	LED
