Leuze HT46C/4P-M12 50127048 Diffuse Sensor with Background Suppression
The HT46C/4P-M12 is a high-precision Diffuse Sensor with Background Suppression (Part No. 50127048) by Leuze, featuring extended sensing range, fast switching response, and M12 industrial interface. The Leuze Diffuse Sensor series ensures accurate object detection while ignoring background surfaces, supporting seamless integration into automated production and assembly lines.
| Brand | Leuze |
| Product | Diffuse Sensor with Background Suppression |
| Model Number | HT46C/4P-M12 |
Leuze HT46C/4P-M12 50127048 Diffuse Sensor with Background Suppression - Technical Specifications
| Specification | Value |
|---|---|
| Operating principle | Diffuse reflection principle with background suppression |
| Beam path | Focused |
| Thread Size | M12 |
| Operating Range | Guaranteed operating range |
| Adjustment range | 120 ... 3,000 mm |
| Wavelength | 630 nm |
| Light Source | LED, Red |
| Supply Voltage | 10 ... 30 V, DC, Incl. residual ripple |
| Open-circuit current | 0 ... 30 mA |
| Digital Switching Outputs | 2 Piece(s) |
| Switching Frequency | 250 Hz |
| Connection Type | Connector |
| No. of Pin | 4 -pin |
| Housing Material | Plastic |
| Plastic housing | PC-PBT |
| Operating Temperature | -40 ... 60 °C |
| Ambient Temperature, Storage | -40 ... 70 °C |
| Degree of Protection (IP Rating) | IP 67, IP 69K |
| Dimension (W x H x L) | 20.5 mm x 76.3 mm x 44 mm |
| Net weight | 60 g |
| Type of display | LED |
| Switching element | Transistor, PNP |
| Switching principle | Light switching |
| Response time | 2 ms |
| Material | Plastic |
| Type | Digital switching output |
The HT46C/4P-M12 (Part No. 50127048) operates using diffuse reflection with background suppression, emitting a light beam and detecting objects within a defined range while filtering out distant or reflective surfaces. It converts optical signals into electrical outputs, providing precise detection for both moving and stationary components in high-speed industrial processes.
Industrially, the HT46C/4P-M12 (Part No. 50127048) is applied for part presence monitoring, position verification, and quality control. Common applications include conveyor systems, automated assembly lines, and packaging operations where accurate detection without interference from background surfaces ensures consistent product quality and process efficiency.
Engineered for demanding industrial environments, the HT46C/4P-M12 (Part No. 50127048) features robust housing, resistance to dust and ambient light interference, and stable operation across temperature variations. Its durable construction guarantees long-term reliability in continuous production and harsh factory conditions.
