Omron HL-5030 Adjustable Rod Lever Limit Switch
The Omron HL-5050 is an Adjustable Rod Lever Limit Switch engineered for accurate mechanical position detection in industrial automation environments. Designed with a compact and rigid metal housing, this limit switch supports AC and DC control circuits up to 250 VAC / 250 VDC, delivering stable and repeatable switching performance under continuous operation. The adjustable stainless-steel rod lever allows precise alignment with cams and moving machine components. Manufactured by Omron, the HL-5050 is part of the Omron Limit Switch, recognized for economical design, rigid construction, and long service life in light to medium-duty industrial applications.
| Brand | Omron |
| Product | Limit Switch |
| Model Number | HL-5050 |
Omron HL-5030 Adjustable Rod Lever Limit Switch ā Technical Overview
| Specification | Value |
|---|---|
| Actuator | Adjustable rod lever |
| Current Rating | 5 A |
| Voltage Rating | 250 VAC / 250 VDC |
| Contact Configuration | 1NO + 1NC |
| Mechanical Life | 10,000,000 operations min. |
| Degree of protection | IP65 |
| Operating Speed | 5 mm/s to 0.5 m/s |
| Insulation Resistance | 100 MĪ© minimum (500 VDC) |
The Omron HL-5050 is widely recognized as an adjustable rod lever limit switch engineered for dependable mechanical position sensing in industrial automation systems. Its rod lever actuator enables linear contact with moving parts, providing smooth actuation and consistent switching performance across repeated cycles.
In industrial applications, the Omron HL-5050 limit switch is commonly used in printing machines, forming machines, conveyors, and light-duty automation equipment where precise travel detection is required. The adjustable rod length supports accurate actuation from cams, guides, and sliding mechanisms while maintaining stable contact operation.
Designed for long-term operational reliability, the Omron HL-5050 offers high mechanical endurance, strong insulation characteristics, and resistance to vibration and shock. With IP65 protection and compliance with industrial electrical standards, this adjustable rod lever limit switch supports continuous operation in demanding industrial environments.
